Vessels & Tanks

Vessels & Tanks

We are one of the well-reputed vessels and tanks manufacturers, suppliers, and exporters of an extensive range of Pharmaceutical Vessels & Tanks that comprises Pressure Vessel, Filling Vessel, and CIP vessel. Designing these products under the supervision of diligent and dedicated personnel, who hold versatile knowledge in their respective domain to meet the defined industry standards and are resistant to hazards such as poisonings, stifle, fires, and explosion hazards. Customers can buy these maintenance-free vessels from us at economical prices.



FILLING VESSEL

Made out of AISI 316 quality S.S. specially designed for sterile solution. Outlet nozzle fitted with a long pipe, which draws out all the liquids from the container. Top lid clamping type fitted with a glass for visual inspection. Vessel is argon arc welded with smooth finished corners and highly polished from inside and out side. The vessel is provided with 2 handles for lifting with S.S. 304 trolley with castor wheels. Complete as per our standard. This  vessels are tested at 2 bar pressure ,  round in shape at top.

Capacities available 50 ltrs, 100 ltrs, 200 ltrs, 300 ltrs, 500 ltrs



    • We manufactured as per the client’s requirements and space available for installations. These are available in various designs and options such as –
    • Bare storage tanks with loose top lid & either flat or dished bottom.
    • Manufacturing vessels with agitators.
    • Reactors
    • Vessels under vacuum / without vacuums.
    • Jacketed vessels and tanks.
    • Vessels and tanks with limped coils etc.
    • Horizontal, capsule-shaped tanks are available.
    • AVAILABLE CAPACITIES : 50 Ltrs. To 10,000 Ltrs.



Made out of 16 gauges AISI 316 complete with ring cover, wing nuts and neoprene gasket. Bent out-let nozzle will be fitted with S. S. Pipe to draw out all the fluid from the vessel. Inlet nozzle for allowing pressurized air. This  vessels are tested at 4 bar pressure , conical in shape at top.



  • The vessel will be fitted with one safety valve and two falling down handles.
  • All welding work will be done by Argon Arc S.S. 316 quality to give smooth finish.
  • Vessel is mirror polished from inside and outside

Capacities available 50 ltrs, 100 ltrs, 200 ltrs, 300 ltrs, 500 ltrs
